Spherical Plain Bearing Series E  -  Maintenance Free
Series GE..EC (-2RS)
Spherical Plain Bearings, steel running on PTFE, maintenance free







For use at high uni-directional loads

Size
(D)		 B M A O dK Static
load Co
kN		 Static
load C   kN
-2RS
 Dynamic
load Co
kN		 Dynamic
load C kN -2RSW
 Pivoting
angle
 α 		Weight
g

4 0
-0,008

 5 3

12 0
-0,008

 6,0 8,0 5,4 - 2,1 - 16 3
5 0
-0,008		 6 4 14 0
-0,008		 8,0 10,0 9,1 - 3,6 - 13 4

6 0
-0,008

 6 4

14 0
-0,008

 8,0 10,0 9,1 - 3,6 - 13 4
8 0
-0,008		 8 5 16 0
-0,008		 10,2 13,0 14,0 - 5,8
 - 15 7
10 0
-0,008		 9 6 19 0
-0,009		 13,2 16,0 21,0 - 8,6 - 12 11
12 0
-0,008		 10 7 22 0
-0,009		 14,9 18,0 28,0 - 11,0 - 11 17
15 0
-0,008		 12 9 26 0
-0,009		 18,4 22,0 45,0 59,0 18,0 17,5 8 26
16 0
-0,008		 14 10 30 0
-0,009		 20,7 25,0 56,0 56,0 22,0 22,5 10 40
17 0
-0,008		 14 10 30 0
-0,009		 20,7 25,0 56,0 75,0 22,0 22,5 10 40
20 0
-0,010		 16 12 35 0
-0,011		 24,1 29,0 78,0 104,0 31,0 31,5 9 64
25 0
-0,010		 20 16 42 0
-0,011		 29,3 35,5 127,0 204,0 51,0 51,0 7 115
30 0
-0,010		 22 18 47 0
-0,011		 34,2 40,7 166,0 263,0 65,0 66,0 6 149
35 0
-0,012		 25 20 55 0
-0,013		 39,7 47,0 211,0 338,0 84,0 140,0 6 228
40 0
-0,012		 28 22 62 0
-0,013		 45,0 53,0 262,0 419,0 104,0 185,0 7 318
45 0
-0,012		 32 25 68 0
-0,013		 50,7 60,0 337,0 540,0 135,0 240,0 7 421
50 0
-0,012		 35 28 75 0
-0,013		 55,9 66,0 415,0 665,0 166,0 295,0 6 562
55 0
-0,015		 40 32 85 0
-0,015		 62,3 74,0 - 852,0 - 355,0 7 864
60 0
-0,015		 44 36 90 0
-0,015		 66,8 80,0 - 1030,0 - 460,0 6 1030
70 0
-0,015		 49 40 105 0
-0,015		 77,8 92,0 - 1320,0 - 590,0 6 1570
80 0
-0,015		 55 45 120 0
-0,015		 89,4 105,0 - 1700,0 - 750,0 6 2320
90 0
-0,020		 60 50 130 0
-0,018		 98,1 115,0 - 2070,0 - 920,0 5 2790
100 0
-0,020		 70 55 150 0
-0,018		 109,5 130,0 - 2570,0 - 1145,0 7 4440
110 0
-0,020		 70 55 160 0
-0,025		 121,2 140,0 - 2770,0 - 1230,0 6 4830
120 0
-0,020		 85 70 180 0
-0,025		 135,5 160,0 - 4030,0 - 1790,0 6 8110
140¹ 0
-0,025		 90 70 210 0
-0,030		 155,8 180,0 - 4530,0 - 2010,0 7 11200
160¹ 0
-0,025		 105 80 230 0
-0,030		 170,2 200,0 - 5760,0 - 2560,0 8 14100
180¹ 0
-0,025		 105 80 260 0
-0,035		 198,9 225,0 - 6480,0 - 2880,0 6 18500
200¹ 0
-0,030		 130 100 290 0
-0,035		 213,5 250,0 - 9000,0 - 4000,0 7 28400
220¹ 0
-0,030		 135 100 320 0
-0,040		 239,5 275,0 - 9900,0 - 4400,0 8 35700
240¹ 0
-0,030		 140 100 340 0
-0,040		 265,3 300,0 - 10800,0 - 4800,0 8 39700
260¹ 0
-0,035		 150 110 370 0
-0,040		 288,3 325,0 - 12870,0 - 5700,0 7 51500
280¹ 0
-0,035		 155 120 400 0
-0,040		 313,8 350,0 - 15120,0 - 6700,0 6 64900
300¹ 0
-0,035		 165 120 430 0
-0,045		 336,7 375,0 - 16200,0 - 7200,0 7 77600

Materials:

Insert: bearing steel to 100Cr6, Aisi 52100, with PTFE liner, bonded to the inner surface
from size 15 available sealed from both sides (-2RS)
from size 55 only sealed from both sides (-2RS)
Ball: bearing steel to 100Cr6, Aisi 52100, hardened, ground, polished, hard chrome plated
¹ from size 140 the hardened inserts are two pieced and secured with tension spring
